Description:
1. Used For Various Vibration Triggering Functions, Reporting Burglary Alarms, Smart Cars, Electronic Building Blocks, Etc.
2. The Comparator Output, The Signal Is Clean, The Waveform Is Good, The Driving Ability Is Strong, More Than 15mA.
1. Used For Various Vibration Triggering Functions, Reporting Burglary Alarms, Smart Cars, Electronic Building Blocks, Etc.
2. The Comparator Output, The Signal Is Clean, The Waveform Is Good, The Driving Ability Is Strong, More Than 15mA.
Specification:
1. Vibration Sensor: SW-420
2. Working Voltage: 3.3V-5V
3. Output Form: Digital Switch Output (0 And 1)
4. Wide Voltage Comparator: LM393
5. Baud rate: 9600
6. Size: 2.8cm X 1.4cm
7. Aperture: 3.1mm
8. Material: Metal
9. Weight: 2.1g
10. Product Usage: Vibration Induction Triggering, Alarm Triggering
Uses:
This Vibration Sensor can be used to detect vibration from any angle. There is an on-board potentiometer to adjust the threshold of vibration. It outputs logic HIGH when this module not triggered while logic Low when triggered.
Application:
•Automobile alarm.
•Movement detection.
•Vibration detecting Applications Features
Package Including:
1PC * Vibration Sensor Module
